Technical parameters
| Model | AX-30 | AX-60 | AX-90 |
 |
|
|
|
| Rated Voltage | 12V | 12V | 12V |
| Rated Power(W) | 5W | 5W | 5W |
| Standby Power(W) | 0.5W | 0.5W | 0.5W |
| Dimension | 208*226*69mm | 208*226*69mm | 208*226*69mm |
Performance Parameters
| Particulate Matter(CADR) | 22m³/h | 22m³/h | 30m³/h |
| TVOC(CADR) | 7m³/h | / | / |
| Noise(4-fan speed) | 55db | 55db | 55db |
| Air Delivering Mode | air inlet on both sides, outlet on one side | air inlet on both sides, outlet on one side | air inlet on both sides, outlet on one side |
Filter Configuration
| Filter Configuration | Activated carbon Composite filter | Activated carbon Composite filter | H13 HEPA filter/Activated carbon Composite filter |
Accessories
| Cable Wiring(M) | 3.5 | 3.5 | 3.5 |
| Bluetooth connection | Yes | Yes | Yes |
| Built-in particle sensor | Yes | Yes | Yes |
| Built-in carbon dioxide sensor | No | Yes | Yes |
| Aluminum support | No | No | Yes |
| Vehicle suction cup/ support | No | No | No |
| Fixed strap | Yes | Yes | Yes |
Intelligent parameter
| Air environment detection function | PM2.5 detection | PM2.5 and CO2 detection | PM2.5 and CO2 detection |
| Operation mode | Manual mode/ Intelligent mode | Manual mode/ Intelligent mode | Manual mode/ Intelligent mode |
Installation steps
| Installation steps | Flat/strap | Flat/stand/strap | Flat/stand/strap |
